ZENITH 844 A Multi-Layer Machine

At MAC Cement Industries, we lead the way in precision and efficiency with the Zenith Model 844. Powered by advanced German technology, this fully automated system ensures the production of high-quality cement blocks and pavers with exceptional speed, strength, and sustainability.

Model 844: The Ultimate Solution for High-Quality Interlocking Paver Production

At MAC Cement Industries, we utilise the Zenith Model 844, a world-class, fully automatic, stationary multilayer machine, to produce top-quality interlocking pavers and similar products.

This advanced machine, the result of decades of research and the latest German technology, is central to our commitment to high performance, simple operation, and minimal maintenance.

The innovative Touch-Operator Panel, featuring a visualised
menu navigation system, makes operating the Model 844 seamless and intuitive, ensuring that all machine functions
are easy to control.

Precision and Flexibility
in Production


The Model 844 is capable of producing products ranging from 50 mm to 500 mm, allowing MAC Cement to manufacture a wide variety of pavers, curbstones, and landscaping products with precision. The machine’s modular components enable full automation of the entire production sequence, from mixing to finished blocks, all ready for transport. With the addition of storage systems and robotic curing, we ensure efficiency at every stage of production.

Unmatched Efficiency
and Performance


When focused on paving stone production, the Zenith Model 844 far surpasses single pallet plants in terms of price-performance ratio, installation time, and ease of handling.
At MAC Cement, we are proud to partner with Zenith to bring our customers the most advanced production solutions, backed by over 65 years of expertise.

MAC Cement:
Building with Excellence

With Zenith’s cutting-edge technology
and MAC Cement’s dedication to quality, we ensure that every block and paver produced is built to last, providing our clients with superior products for any construction project.

Concrete Mixer Truck Capacit:
2,100 liters If the desired cubic stone height, pallet size, or required product height is
not specified, we would be happy to explore the possibility of designing a custom solution
that better fits your needs.
Machine Weight:
With front mixing unit: 16,000 kg Including conveyor belts, operating platform, hydraulic
station, pallet holder, etc.: 9,000 kg
Machine Dimensions:
Maximum overall length: 6,200 mm
Maximum overall height (during transport): 3,000 mm
Maximum overall width: 2,470 mm



Standard Pallet Size:
1,270 X 1,050 X 125 mm
Maximum Production Area:
1,240 X 1,000 mm
Block Height:
Maximum: 500 mm
Minimum: 50 mm
Optional Block Height: 35 mm
Cube Height:
Maximum: 640 mm
